| Nominal Pipe Size (NPS) |
Outside Diameter at Bevel (O/D) |
End to End |
Nominal Pipe Size (NPS) |
Outside Diameter at Bevel (O/D) | End-to-End | ||
|---|---|---|---|---|---|---|---|
| Run | Outlet | H | Run | Outlet | H | ||
| ¾'' x ½'' ¾'' x 3/8'' |
26.7 26.7 |
21.3 17.3 |
38 38 |
12'' x 10'' 12'' x 8'' 12'' x 6'' 12'' x 5'' | 323.8 323.8 323.8 323.8 |
273.0 219.1 168.3 141.3 |
203 203 203 203 |
| 1'' x ¾'' 1'' x ½'' |
33.4 33.4 |
26.7 21.3 |
51 51 |
||||
| 1.1/4'' x 1'' 1.1/4'' x ¾'' 1.1/4'' x ½'' |
42.2 42.2 42.2 |
33.4 26.7 21.3 |
51 51 51 |
14'' x 12'' 14'' x 10'' 14'' x 8'' 14'' x 6'' | 355.6 355.6 355.6 355.6 |
323.8 273.0 219.1 168.3 |
330 330 330 330 |
| 1.1/2'' x 1.1/4'' 1.1/2'' x 1'' 1.1/2'' x ¾'' 1.1/2'' x ½'' |
48.3 48.3 48.3 46.3 |
42.2 33.4 26.7 21.3 |
64 64 64 64 |
16'' x 14'' 16'' x 12'' 16'' x 10'' 16'' x 8'' | 406.4 406.4 406.4 406.4 |
355.6 323.8 273.0 219.1 |
356 356 356 356 |
| 2'' x 1.1/2'' 2'' x 1.1/4'' 2'' x 1'' 2'' x ¾'' |
60.3 60.3 60.3 60.3 |
48.3 42.2 33.4 26.7 |
76 76 76 76 |
18'' x 16'' 18'' x 14'' 18'' x 12'' 18'' x 10'' | 457.0 457.0 457.0 457.0 |
406.4 356.6 323.8 273.0 |
381 381 381 381 |
| 2.1/2'' x 2'' 2.1/2'' x 1.1/2'' 2.1/2'' x 1.1/4'' 2.1/2 x 1'' |
73.0 73.0 73.0 73.0 |
60.3 48.3 42.2 33.4 |
89 89 89 89 |
20'' x 18'' 20'' x 16'' 20'' x 14'' 20'' x 12'' | 508.0 508.0 508.0 508.0 |
457.0 406.4 355.6 323.8 |
508 508 508 508 |
| 3'' x 2.1/2'' 3'' x 2'' 3'' x 1.1/2'' 3'' x 1.1/4'' |
88.9 88.9 88.9 88.9 |
73.0 60.3 48.3 42.2 |
89 89 89 89 |
22'' x 20'' 22'' x 18'' 22'' x 16'' 22'' x 14'' | 559.0 559.0 559.0 559.0 |
508.0 457.0 406.4 355.6 |
508 508 508 508 |
| 3.1/2'' x 3'' 3.1/2'' x 2.1/2'' 3.1/2'' x 2'' 3.1/2'' x 1.1/2'' |
101.6 101.6 101.6 101.6 |
88.9 73.0 60.3 48.3 |
102 102 102 102 |
24'' x 22'' 24'' x 20'' 24'' x 18'' 24'' x 16'' | 610.0 610.0 610.0 610.0 |
559.0 508.0 457.0 406.4 |
508 508 508 508 |
| 4'' x 3.1/2'' 4'' x 3'' 4'' x 2.1/2'' 4'' x 2'' 4'' x 1.1/2'' |
114.3 114.3 114.3 114.3 114.3 |
101.6 88.9 73.0 60.3 48.3 |
102 102 102 102 102 |
26'' x 24'' 26'' x 22'' 26'' x 20'' 26'' x 18'' | 660.0 660.0 660.0 660.0 |
610.0 559.0 508.0 457.0 |
610 610 610 610 |
| 5'' x 4'' 5'' x 3.1/2'' 5'' x 3'' 5'' x 2.1/2'' 5'' x 2'' |
141.3 141.3 141.3 141.3 141.3 |
114.3 101.6 88.9 73.0 60.3 |
127 127 127 127 127 |
28'' x 26'' 28'' x 24'' 28'' x 20'' 28'' x 18'' | 711.0 711.0 711.0 711.0 |
660.0 610.0 508.0 457.0 |
610 610 610 610 |
| 6'' x 5'' 6'' x 4'' 6'' x 3.1/2'' 6'' x 3'' 6'' x 2.1/2'' |
168.3 168.3 168.3 168.3 168.3 |
141.3 114.3 101.6 88.9 73.0 |
140 140 140 140 140 |
30'' x 28'' 30'' x 26'' 30'' x 24'' 30'' x 20'' | 762.0 762.0 762.0 762.0 |
711.0 660.0 610.0 508.0 |
610 610 610 610 |
| 8'' x 6'' 8'' x 5'' 8'' x 4'' 8'' x 3.1/2'' |
219.1 219.1 219.1 219.1 |
168.3 141.3 114.3 101.6 |
152 152 152 152 |
32'' x 30'' 32'' x 28'' 32'' x 26'' 32'' x 24'' | 813.0 813.0 813.0 813.0 |
762.0 711.0 660.0 610.0 |
610 610 610 610 |
| 10'' x 8'' 10'' x 6'' 10'' x 5'' 10'' x 4'' |
273.0 273.0 273.0 273.0 |
219.1 168.3 141.3 114.3 |
178 178 178 178 |
34'' x 32'' 34'' x 30'' 34'' x 26'' 34'' x 24'' | 864.0 864.0 864.0 864.0 |
813.0 762.0 660.0 610.0 |
610 610 610 610 |
